Product Introduction
The solar cell is the most critical core component in the production of solar panels. As the heart of the module, it is responsible for converting sunlight directly into electricity through the photovoltaic effect. The performance and quality of solar cells largely determine the efficiency, durability, and overall value of the final solar panel.
At Ooitech, we not only provide advanced solar cell processing equipment but also help our partners understand the latest developments in cell technologies, ensuring that every production line is aligned with industry innovation and market demand.
A solar cell, the fundamental component of any solar panel, converts sunlight directly into DC electricity through the photovoltaic effect. Modern manufacturing requires precision equipment to process these semiconductor devices, from laser cutting to tabbing and stringing, ensuring optimal electrical connections when hundreds of cells are assembled into modules.
Our comprehensive equipment portfolio supports all mainstream cell technologies:
Polycrystalline cells with their distinctive blue pattern
Monocrystalline PERC cells - the current industry standard
TOPCon n-type cells - the fastest-growing technology
HJT heterojunction cells - ultra-high efficiency solutions
Technical Specifications
Supported Cell Technologies and Equipment Capabilities
| Technology Type | Cell Efficiency Range | Equipment Compatibility | Production Capacity |
|---|
| Polycrystalline | 18-20% | Full line support | 5MW - 1GW |
| Mono PERC | 22-23.5% | Advanced MBB processing | 5MW - 1GW |
| TOPCon | 23.5-25%+ | N-type optimized | 5MW - 1GW |
| HJT | 24-25.5%+ | Low-temperature handling | 5MW - 1GW |
| IBC/ABC/HPBC | 24-26% | Specialized equipment | 5MW - 1GW |
| Shingled | Variable | Precision cutting/assembly | 5MW - 1GW |
Cell Size Compatibility
| Size Format | Dimensions (mm) | Busbar Configuration | Equipment Support |
|---|
| G1 (M0) | 156.75 × 156.75 | 5BB-12BB/MBB | ✓ Full support |
| M6 | 166 × 166 | 5BB-12BB/MBB | ✓ Full support |
| M10 | 182 × 182 | 9BB-16BB/MBB | ✓ Full support |
| M12 | 210 × 210 | 11BB-18BB/MBB | ✓ Full support |
Key Equipment Specifications
| Equipment Type | Processing Speed | Accuracy | Yield Rate |
|---|
| Laser Cutting Machine | Up to 8000 cells/hr | ±0.1mm | >99.5% |
| Tabber Stringer | Up to 3600 cells/hr | ±0.3mm | >99.8% |
| Layup Machine | Up to 120 modules/hr | ±0.5mm | >99.9% |
| Bussing Machine | Up to 3000 cells/hr | ±0.2mm | >99.7% |
| EL Tester | 60-120 modules/hr | 0.1MP resolution | 100% inspection |
Technical Advantages
Advanced Cell Processing Capabilities
Multi-Technology Compatibility: Single production line handles PERC, TOPCon, HJT, and emerging technologies
MBB Technology Excellence: Optimized for 9BB, 12BB, 16BB, and advanced multi-busbar configurations
Precision Engineering: Industry-leading accuracy for half-cell and shingled cell processing
Smart Integration: IoT-enabled equipment with real-time monitoring and predictive maintenance
Temperature Management: Specialized low-temperature processing for HJT and heterojunction technologies
Production Efficiency Features
High-Speed Processing: Up to 8000 cells/hour throughput on cutting equipment
Minimal Breakage: Advanced handling systems reduce cell damage to<0.2%
Flexible Configuration: Quick changeover between different cell sizes (G1 to M12)
Quality Assurance: Integrated EL testing and sun simulator validation at every stage
Energy Efficiency: Optimized power consumption reducing operational costs by 25%
Complete Solution Benefits
Turnkey Projects: From 5MW pilot lines to 1GW mega-factories
Training Programs: Comprehensive operator and maintenance training included
Raw Material Supply: Complete supply chain support for consumables and spare parts
Industry 4.0 Ready: MES integration and automated data collection systems
Global Standards: CE certified equipment meeting international safety requirements
Product Applications
Manufacturing Scenarios
High-Efficiency Module ProductionOur equipment excels in producing premium modules using TOPCon and HJT cells, achieving module efficiencies exceeding 22%. The precision tabbing and stringing equipment ensures minimal cell-to-module (CTM) losses, maximizing the power output of finished panels.
Specialized Product Lines
Bifacial Modules: Equipment optimized for transparent backsheet and dual-glass configurations
Half-Cell Technology: Precision laser cutting for reduced resistance and improved shade tolerance
Shingled Modules: Advanced adhesive application and cell overlapping systems
Flexible Panels: Specialized handling for thin-film and CIGS technologies
Large-Scale ManufacturingFrom emerging manufacturers establishing their first 5MW pilot line to industry leaders expanding to gigawatt-scale production, our scalable solutions grow with your business. Recent installations include:
500MW TOPCon production lines in Southeast Asia
1GW PERC upgrade projects in India
200MW HJT demonstration facilities in Europe
Industry Applications
Utility-Scale Projects: Equipment for manufacturing high-power modules (>600W) for solar farms
Commercial Rooftop: Production lines for lightweight, high-efficiency panels
Residential Systems: Manufacturing aesthetic all-black modules with superior performance
BIPV Applications: Specialized equipment for building-integrated photovoltaic products
Off-Grid Solutions: Flexible manufacturing for portable and specialty solar products
