Product Introduction
The Offline Frame Gluing Machine Model BD03 is an advanced automated solution designed specifically for applying sealant to aluminum frames in solar panel manufacturing processes. This professional-grade equipment represents the latest innovation in frame preparation technology, offering manufacturers a reliable and efficient method to ensure perfect sealant application before the framing process. Built by Ooitech, a leading provider of solar panel production line equipment ranging from 5MW to 1GW capacity, this machine combines precision CNC control with user-friendly operation to deliver consistent, high-quality results in industrial solar module assembly applications.
Technical Parameters
| Parameter | Specification |
|---|
| Maximum Processing Length | 2500mm |
| Minimum Processing Length | 300mm |
| Maximum Processing Width | 50mm |
| Minimum Processing Width | 17mm |
| Working Speed | 3-4 seconds/meter |
| Glue Type | 270kg/drum |
| Power Supply | 220V/50Hz |
| Power Consumption | 1.0KW |
| Air Pressure Requirement | 0.5MPa |
| Machine Weight | 400KG |
| Control System | CNC Programmable |
| Loading Method | Manual |
| Gluing Method | Automatic |
Technical Advantages
CNC System Control Excellence
Precision Control: Advanced CNC system ensures accurate positioning and consistent glue application
Automatic Operation: Automated feeding, positioning, and gluing processes minimize manual intervention
Frame Support: No manual frame support required during gluing process, reducing operator fatigue
Superior Gluing Performance
Uniform Application: Ensures even and complete sealant distribution across entire frame length
Single-Pass Efficiency: Eliminates need for secondary glue application after framing
Material Savings: Optimized glue consumption reduces waste and operational costs
Time Efficiency: Significantly reduces production time compared to manual application
User-Friendly Operation
Stepless Speed Control: Computer-controlled variable speed adjustment for both glue application and transmission
Simple Interface: Intuitive control panel for easy operation and parameter adjustment
Quick Setup: Minimal training required for operators
Reliable Pneumatic System
Stable Performance: Pneumatic glue supply system ensures consistent pressure and flow
Low Maintenance: Simple and robust design minimizes downtime
Large Capacity: Accommodates 270kg drums for extended production runs
Product Applications
Solar Panel Manufacturing
The BD03 is specifically designed for integration into solar panel production lines, serving as a critical component in the module assembly process. It prepares aluminum frames with precise sealant application before they are attached to laminated solar panels, ensuring weatherproof sealing and long-term durability of the finished modules.
Compatible Module Types
Standard Solar Panels: G1, M6, M10, M12 size modules
Advanced Technologies: PERC, TOPCon, IBC, ABC, HPBC solar cells
Specialized Modules: Shingled, flexible, and thin-film solar panels
Various Power Ranges: Suitable for production lines from 5MW to 1GW capacity
Industrial Applications
Large-Scale Production: Ideal for high-volume solar panel manufacturing facilities
Quality Control: Ensures consistent frame preparation meeting international standards
Retrofit Solutions: Can be integrated into existing production lines for capacity enhancement
Custom Manufacturing: Adaptable for specialized module sizes within specified parameters
